OSD 70V Commercial Multi Channel Amplifier 6 Zones, 60W per Channel, Multi Use 70V /8 Ohm/ 4 Ohm

SOUND QUALITY: The PAM-1270 puts out 60 Watts per channel and can operate as 6 independent stereo zone amplifiers or 12 zone mono channels. It’s the perfect foundation for a custom home theater stereo.POWER: This amplifier is a 12-channel Class D amp that supplies clean power to hear every detail in music and movies with accuracy. It can be matched with in-wall or freestanding loudspeakers.DESIGN: A brushed metal finish and front panel indicators add a high-tech ambiance to any equipment rack. It is designed with a high-output power supply and ample heat to keep things cool.INSTALLATION: There are both balanced and unbalanced inputs for flexible installation options and long or short cable runs.MOUNT: The PAM-1270 is designed to mount into standard 19 inch racks or on flat, horizontal surfaces. It can be placed in numerous locations in your house.

	PA90	PA150	PAM1270	MX1260	PAM245	PRE-1
Amplifier Class	Class A/B	Class A/B	Digital Class D	Class A/B	Digital Class D
Number of Channels	1	1	12	12	5
Power Handling per Channel @ 8 Ohms	30W(RMS)/ 60W(MAX)	60W(RMS)/ 120W(MAX)	30W(RMS)/ 60W(MAX)	40W(RMS)/ 80W(MAX)	120W(RMS)/ 240W(MAX)
Power Handling per Channel @ 4 Ohms			50W(RMS)/ 100W(MAX)	60W(RMS)/ 120W(MAX)	240W(RMS)/ 480W(MAX)
Frequency Response	55Hz-15kHz, (+0dB, -3.0dB)	55Hz-15kHz, (+0dB, -3.0dB)	20Hz-20kHz+/-1 dB	20Hz - 20kHz	55Hz-15kHz, (+0dB, -3.0dB)	5Hz - 30kHz +0 -3dB
Impedance	8 Ohms	8 Ohms	8 Ohm and 4 Ohm Stable	8 Ohm and 4 Ohm Stable	8 Ohm and 4 Ohm Stable
Auto-On Sensing	✓	✓	✓	✓	✓
Dimensions (L x H x D):	(L x D x H): 19" x 13.3" x 3.6"	(L x D x H): 19" x 13.3" x 3.6"	(L x H x D): 16.7" x 4" x 14.25"	(L x H x D): 16.7" x 4" x 14.25"	(L x D x H): 16.5" x 12" x 3.5"	(L x D x H): 18.9" x 8.25" x 2.36"
Weight	16.5 lbs	21 lbs	34 lbs	34 lbs	13.7 lbs	8 lbs
